Fluke 15B MAX-01 Economical Digital Multimeter WhatsApp: 01955907440

Description

Specifications: Fluke 15B MAX Economical Digital Multimeter
Specifications
Accuracy is specified for 1 year after calibration, at operating temperatures of 18 °C to 28 °C, relative humidity at 0 % to 75 % Accuracy specifications take the form of: ± ([% of Reading] + [Number of Least Significant Digits]).
Function Range Resolution Accuracy
15B MAX 17B MAX
AC Volts (40 Hz to 500 Hz)1 6.000 V
60.00 V
600.0 V
1000 V 0.001 V
0.01 V
0.1 V
1 V 1.0 % + 3 1.0 % + 3
AC Millivolts 600.0 mV 0.1 mV 3.0 % + 3 3.0 % + 3
DC Volts 6.000 V
60.00 V
600.0 V
1000 V 0.001 V
0.01 V
0.1 V
1 V 0.5 % + 3 0.5 % + 3
DC Millivolts 600.0 mV 0.1 mV 1.0 % + 10 1.0 % + 10
AC Current μA (40 Hz to 400 Hz)2 400.0 μA
4000 μA 0.1 μA
1 μA 1.5 % + 3 1.5 % + 3
AC Current mA (40 Hz to 400 Hz)2 40.00 mA
400.0 mA 0.01 mA
0.1 mA 1.5 % + 3 1.5 % + 3
AC Current A (40 Hz to 400 Hz)2 4.000 A
10.00 A 0.001 A
0.01 A 1.5 % + 3 1.5 % + 3
DC Current μA2 400.0 μA
4000 μA 0.1 μA
1 μA 1.5 % + 3 1.5 % + 3
DC Current mA2 40.00 mA
400.0 mA 0.01 mA
0.1 mA 1.5 % + 3 1.5 % + 3
DC Current A2 4.000 A
10.00 A 0.001 A
0.01 A 1.5 % + 3 1.5 % + 3
Diode Test3 2.000 V 0.001 V 10% 10%
Temperature 4 50.0 °C to 400.0 °C
0 °C to 50.0 °C
-55.0 °C to 0 °C 0.1 °C NA 2 %+1 °C
2 °C
9 %+2 °C
Resistance (Ohms)5 400.0 Ω
4.000 kΩ
40.00 kΩ
400.0 kΩ
4.000 MΩ
40.00 MΩ 0.1 Ω
0.001 kΩ
0.01 kΩ
0.1 kΩ
0.001 MΩ
0.01 MΩ 0.5 % + 3
0.5 % + 2
0.5 % + 2
0.5 % + 2
0.5 % + 2
1.5 % + 3 0.5 % + 3
0.5 % + 2
0.5 % + 2
0.5 % + 2
0.5 % + 2
1.5 % + 3
Capacitance6 40.00 nF
400.0 nF
4.000 μF
40.00 μF
400.0 μF
2000 μF 0.01 nF
0.1 nF
0.001 μF
0.01 μF
0.1 μF
1 μF 2 % + 5
2 % + 5
5 % + 5
5 % + 5
5 % + 5
5 % + 5 2 % + 5
2 % + 5
5 % + 5
5 % + 5
5 % + 5
5 % + 5
Frequency1 (10 Hz to 100 kHz) 50.00 Hz
500.0 Hz
5.000 kHz
50.00 kHz
100.0 kHz 0.01 Hz
0.1 Hz
0.001 kHz
0.01 kHz
0.1 kHz NA 0.1 % + 3
Duty Cycle1 1% to 99% 0.10% NA 1 % typical7
Continuity Threshold — — 70Ω 70Ω
Backlight — — Yes Yes
1 All ac, Hz, and duty cycle are specified from 1 % to 100 % of range. Inputs below 1 % of range are not specified.
2 Typical burden voltage: DC/AC Current µA: 100 µV / µA; DC/AC Current mA: 2 mV/mA; DC/AC Current A: 0.03 V/A
3Typically, open circuit test voltage is 2.0 V and short circuit current is <0.6 mA 4Use Type K thermocouple 5 Typical open circuit test voltage is 0.54 V, maximum short circuit current is 1.8 mA 6Specifications do not include errors due to test lead capacitance and capacitance floor (may be up to 1.5 nF in the 40 nF range). 7 Typical means when the frequency is at 50 Hz or 60 Hz and the duty cycle is between 10 % and 90 %. Input Characteristics Function Overload Protection Input Impedance (Nominal) Common Mode Rejection Ratio Normal Mode Rejection Ratio AC Volts 1000 V 1 >10 MΩ, <100 pF >60 dB at 50 Hz or 60 Hz —
AC Millivolts 1000 V 1 >1 MΩ, <100 pF >80 dB at 50 Hz or 60 Hz —
DC Volts 1000 V 1 >10 MΩ, <100 pF >100 dB at 50 Hz or 60 Hz >60 dB at 50 Hz or 60 Hz
DC Millivolts 1000 V 1 >1 MΩ, <100 pF >80 dB at 50 Hz or 60 Hz —
1106 V Hz max
