Description
Specifications
AC Current 60.00/600.0/1000A, 3 ranges, 45Hz to 400Hz, True RMS
Basic accuracy: ±1.5% rdg. ±5dgt. (50/60Hz, filter ON)
AC Voltage n/a
Frequency n/a
Crest Factor 2.8 and under (1.68 and under at 1000 A range)
Filter Function Cut off frequency 180Hz at filter ON (-3dB)
Output Function n/a
Other Function Flip-open mechanism (but still retaining proper orientation of display), Back light, Maximum value display, Data hold, Auto power off
Display Digital LCD, max. 6000dgt., 91 segments
Display refresh rate: 1.1 sec or higher
Power Supply Coin type lithium battery (CR2032) × 1, Continuous use 20 hours
Core Jaw Dia. φ 30mm (1.18 in)
Dimensions, mass 50mm (1.97 in) W × 136mm (5.35 in) H × 26mm (1.02 in) D, 115g (4.1 oz)
